Scantrak
Scantrak is a multi-application portable digital X-ray system with a 20 x 25 cm (8 x 10″) Imaging Area. It is used by a variety of users which include police, military, customs and public safety agencies as well as prison and building managers to search and examine items safely in situ.
Operators control and fire the X-ray generator to remotely capture images using the Scanview software on the laptop controller. Images are transmitted instantaneously via a data cable or wirelessly. Multiple repeat exposures can be taken without the need to re-approach the target.
Supplied in rugged wheeled pelicase with x-ray generator, laptop control and 50m cable on reel.
Safe: The X-ray Generator is controlled from a distance using the system’s Scanview software. Multiple X-rays of varying exposure times can be taken in seconds without the need to re-approach the target.
Simple design: Scantrak is designed to be easy to set up and use. It combines just three core components – ICU, X-ray generator and laptop.
- Technical
- Options
- Downloads
Standard System Configuration
Scantrak
Power Supply
Scantrak systems are fully portable and all components will operate independently using a battery pack for up to 5 hours with no reliance on mains power
Weight
5.5 kg
Receptor
CCD
Dimensions
20 x 25 cm (8 x 10″) Imaging Area
Resolution
1280 x 1024 Pixels
Options
- Wireless Image Transmission 802.11g
- Extended Cable Lengths
- Foreign Language Software
- ROV Robot Integration
- Imager and Generator Tripod Mounts
- External Camera
- Scantrak is supplied with a high performance laptop running Windows 11 Professional
- Minimum spec: Intel Processor, 512 GB SSD, 16 GB Memory
- Other brand name variants and ruggedised MilSpec models with foreign keyboard and OS options are available
